To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
| Number | Items | Unit | Data |
|---|---|---|---|
| 01 | Rated voltage | kV | 12 |
| 02 | Rated current | A | 630 |
| 03 | Rated frequency | Hz | 50 |
| 04 | Rated short circuit breaking current | kA | 20 |
| 05 | Rated peak withstand current | kA | 20 |
| 06 | Rated short-time withstand current | kA | 20 |
| 07 | Rated short circuit breaking current (maximum) | kA | 63 |
| 08 | Mechanical life | Times | 10000 |
| 09 | Rated cable charging current | A | 25 |
| 10 | Power frequency withstand voltage | kV | 42/34 |
| 11 | Lightning impulse withstand voltage | kV | 75 |
| 12 | Rated operating sequence | - | OC-0.3s-CO-180S-CO |
| 13 | mechanism control voltage | V | DC24 |
| 14 | contact opening distance | mm | 9±1 |
| 15 | Exceed range | mm | 2±0.5 |
| 16 | Average break speed | m/s | 0.4~0.8 |
| 17 | Average closing speed | m/s | 0.8~1.2 |
| 18 | The jump time of contact close break | ms | ≤2 |
| 19 | Different periods of brake opening | ms | ≤2 |
| 20 | Different period of three-phase break | ms | ≤2 |
| 21 | Opening time | ms | 20~60 |
| 22 | Closing time | ms | 18~45 |
| 23 | weight | kg | 150 |
| 24 | Rated Duration of Short-circuit | s | 4 |
Our company is a production and sales-oriented enterprise specializing in the manufacturing of power equipment. We integrate design, research and development, manufacturing, and technical services. Our main products include gas-insulated switchgear, ring main units, prefabricated substations, high-voltage switchgear, low-voltage switchgear, cable branch boxes, outdoor switching stations, primary and secondary fusion pole-mounted circuit breaker, and indoor and outdoor high-voltage vacuum circuit breakers.
The products are widely used in various distribution networks, including industrial and mining sectors, transportation, petrochemical and metallurgical industries, residential communities, and ports. Over the years, our products have been sold worldwide, reaching markets in the Americas, Europe, Africa, the Middle East, and Southeast Asia. We adhere to the service philosophy: "What our peers can do is a duty, what our peers cannot do is our service!" and provide comprehensive consulting services to our customers.
