| Type | Microcontroller |
| Place of Origin | China |
| Manufacturer | ST |
| Mfg Date Code | 23-25+ |
| Series | SMT32F103C8T6TR, SMT32F103RCT6TR, STM32F103V8T6TR, STM32F103VBT6TR, STM32F103VCT6TR |
| Description | Microcontrollers |
| Application | Industrial control and automation, Automotive electronics, Smart home and consumer electronics, medical equipment |
| Mounting Type | LQFP64 10*10mm |
| Operating Temperature | -40°C ~ 85°C |
| Core Processor | Core: ARM 32-bit CortexM3 CPU with MPU |
| Co-processor | cortex-M3 |
| Speed | 32MHz |
| Flash Size | 768 K bytes to 1 M byte of Flash memory |
| RAM Size | 64K x 8 |
| Connector Type | SMT |
| Size / Dimension | LQFP64 7*7mm |
| Packaging | Tray |
| Core Size | 32-Bit Single-Core |
| Connectivity | SPI I2C |
| Peripherals | A/D 10*12b |
| Number of I/O | 32 |
| Program Memory Size | 64K |
| Program Memory Type | flash |
| EEPROM Size | 64K x 8 |
| Voltage - Supply (vcc/vdd) | 0 to 3.6 V |
| Data Converters | A/D 10*12b |
| Oscillator Type | Clock 4-to-16 MHz crystal oscillator |
| Controller Series | STM32F103 |
| Interface | SPI I2C |
| Voltage - Supply | 0 to 3.6 V |
| Package / Case | LQFP48 |
| Number of Cores/Bus Width | 32bit |
| RAM Controllers | SRAM |
| Graphics Acceleration | NONE |
| Display & Interface Controllers | NONE |
| Ethernet | Not Applicable |
| USB | USB 2.0 |
| Voltage - I/o | 2V-3.6V |
| Cross Reference | GD32F103C8T6TR |
| Fpga Gates | NONE |
