| Type | Rated standard power of 3-phase motors 50/60HZ in category AC-3 | Setting range(A) | |||||
|---|---|---|---|---|---|---|---|
| 220V | 380V | 415V | 440V | 500V | 660V | ||
| KW | KW | KW | KW | KW | KW | ||
| GV2P01 | -- | -- | -- | -- | -- | -- | 0.1-0.16 |
| GV2P02 | -- | -- | -- | -- | -- | -- | 0.16-0.25 |
| GV2P03 | -- | -- | -- | -- | -- | -- | 0.25-0.4 |
| GV2P4 | -- | -- | -- | -- | -- | 0.37 | 0.4-0.63 |
| GV2P05 | -- | -- | -- | 0.37 | 0.37 | 0.55 | 0.63-1.0 |
| GV2P06 | -- | 0.37 | -- | 0.55 | 0.75 | 1.1 | 1.0-1.6 |
| GV2P07 | 0.37 | 0.75 | 0.75 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| GV2P08 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4.0 |
| GV2P10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4-6.3 |
| GV2P14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6.0-10.0 |
| GV2P16 | 3 | 5.5 | 5.5 | 7.5 | 7.5 | 9 | 9.0-14.0 |
| GV2P20 | 4 | 7.5 | 9 | 9 | 9 | 11 | 13.0-18.0 |
| GV2P21 | 5.5 | 11 | 11 | 11 | 11 | 15 | 17.0-23.0 |
| GV2P22 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 20.0-25.0 |
| GV2P32 | 7.5 | 15 | 15 | 15 | 18.5 | 26 | 24.0-32.0 |
| GV3P06 | -- | 0.37 | -- | 0.55 | 0.75 | 1.1 | 1.0-1.6 |
| GV3P07 | 0.37 | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| GV3P08 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4.0 |
| GV3P10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4.0-6.0 |
| GV3P14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6.0-10.0 |
| GV3P20 | 4 | 7.5 | 7.5 | 7.5 | 10 | 11 | 10.0-16.0 |
| GV3P25 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 16.0-25.0 |
| GV3P40 | 11 | 18.5 | 22 | 22 | 25 | 33 | 25.0-40.0 |
| GV3P63 | 15 | 30 | 33 | 33 | 40 | 55 | 40.0-63.0 |
| GV3P80 | 22 | 40 | 45 | 45 | 55 | 63 | 56.0-80.0 |
